Description
Thermodynamic Steam Trap
The DKV Thermodynamic Steam Trap is a compact and robust solution featuring a simple design with a single moving component—a disc that opens to discharge condensate and closes when steam is present.
Constructed from stainless steel or alloy steel, it can handle pressures up to 3,600 psig.
The DKV steam trap is ideal for high-pressure drip applications and critical tracing operations.
| Type | DN | Size(mm) | |||||||
| CS49H-16 | L | D | D1 | D2 | b-f | z-d | H1 | H2 | |
| 15 | 150 | 95 | 65 | 45 | 14-2 | 4-14 | 60 | 60 | |
| 20 | 150 | 105 | 75 | 55 | 16-2 | 4-14 | 62 | 65 | |
| 25 | 160 | 115 | 85 | 65 | 16-2 | 4-14 | 65 | 70 | |
| 32 | 230 | 135 | 100 | 80 | 18-2 | 4-18 | 70 | 75 | |
| 40 | 230 | 145 | 110 | 85 | 18-2 | 4-18 | 75 | 88 | |
| 50 | 230 | 160 | 125 | 100 | 20-3 | 4-18 | 80 | 95 | |
| Model | Size | DN | Connection Type | Maximum Allowable Temperature | Dimensions | Weight （KG） | ||
| L | H1 | H2 | ||||||
| CS49H | 1/2″ | 15 | Flanged End (DIN,JIS,ANSI) | ≤425℃ | 150 | 55 | 50 | 2.5 |
| CS49H | 3/4″ | 20 | Flanged End (DIN,JIS,ANSI) | ≤425℃ | 150 | 55 | 58 | 2.9 |
| CS49H | 1″ | 25 | Flanged End (DIN,JIS,ANSI) | ≤425℃ | 160 | 58 | 62 | 3.5 |
| CS49H | 1-1/4″ | 32 | Flanged End (DIN,JIS,ANSI) | ≤425℃ | 210 | 71 | 80 | / |
| CS49H | 1-1/2″ | 40 | Flanged End (DIN,JIS,ANSI) | ≤425℃ | 210 | 75 | 90 | / |
| CS49H | 2″ | 50 | Flanged End (DIN,JIS,ANSI) | ≤425℃ | 230 | 85 | 105 | / |
Item | Value |
Type | Steam Trap |
Structure | Control |
Application | General |
Place of Origin | China |
Power | Manual |
Customized Support | OEM, ODM |
Port Size | DN15-DN50 |
Warranty | 1 year |
Model Number | CS49H-16C |
Temperature of Media | Normal Temperature |
Brand Name | DKV |
Connection | Flange |
Body Material | Carbon Steel WCB |
Working Pressure | 16K |
Working Temperature | 0℃ to 300℃ |
Working Medium | Air Water Oil Gas Acid |
Product Details
