Description
The DKV globe valve series is available in sizes from ½” to 24″ and complies with ANSI Pressure Class 150# to 1500# standards.
Manufactured from carbon steel, stainless steel, brass, or cast iron, these valves can be equipped with spring return, non-spring return, or electronic fail-safe actuators to suit different operational needs.
With options for NPT/BSP threaded or flanged end connections, DKV globe valves deliver versatility, reliability, and durability for a wide range of industrial applications.
item | value |
structure | Globe |
application | General |
place of origin | China |
power | Manual |
customized support | OEM, ODM |
port size | DN15- DN300 |
warranty | 1 year |
temperature of media | Medium Temperature |
brand name | DKV |
media | Steam |
Body material | Stainless Steel 304/316L;WCB |
Connection | Flange |
Medium | water,oil,steam |
Size | DN15-400 |
Working pressure | CL150~2500Lb, PN1.6~16MPa |
Work Temperature | -29~+425℃(WCB), -40~+200℃(SS) |
Product Details
Body material : Stainless Steel
Size: DN15-DN300
Connection : DIN Flange
Pressure range: CLASS150/300/600
Temperature range: -10 to 400C
Application: Steam, Water, Gas, Oil, Air
